Automatic Loading And Unloading Design Non Woven Bag Making Machine

Ask Lasest Price
Brand Name :	OUNUO
Certification :	CE
Model Number :	ONL-C700
Delivery Time :	30 days
Payment Terms :	T/T,L/C at sight
Supply Ability :	40 set/month
Price :	USD15000/SET

Add to Cart

Product Details
Company Profile

Automatic Loading And Unloading Design Non Woven Bag Making Machine

Automatic Loading And Unloading Design Non Woven Bag Making Machine

Main technical parameters:

700Model
Non woven bag	Flat bag	Handle bag	T-shirt bag	Box bag
Non wove bag length(mm)	100-800	100-800	100-800	100-800
Non woven bag width(mm)	100-580	100-580	100-580	100-580
Bag making speed(pcs/min)	20-100	20-80	20-80	20-60
Non woven fabric thickness(G/M2)	30-100	30-100	30-100	30-100
Rewinding material width	1300mm
Machine weight	2500kg
Power Supply	220V, 50HZ, Single Phase
Total Power	21kw
Overall Dimension	1100019501800
Air compressor	10.2kw
Handle sealing part	6 Set Top quality ultrasonic
Loop handle length	400-600mm
Loop handle Width	250-300mm
Diameter	800mm
Handle loop fabric Weight	60-120gsm

Main Introductions :

This machine is the present domestic function is the most complete, the performance is the most stable automatic non-woven bag making machine. On the basis of the original bag making machine, add automatic bonding handle. That is real liberating manual and fully automatic production of non-woven bag. It compared with the similar machine, higher precision, less waste, faster and achieved maximum benefit for you.

Performance and Characteristics:

This machine widely used in producing non-woven handle bag, flat bag, box bag, T-shirt bag, organ bag, gift bag, pillow bag, drawstring bag, etc. The produce different bags as long as change the way of material. It is simple operation, high efficiency and good stability. The whole machine adopts microcomputer control and material pulling by stepping motor. Automatic positioning and bonding handle. It arbitrary fixed length, accurate and stable step photoelectric tracking, automatic punching, counting, alarming and stopping when the label is lost.

Advantages:

1. One set computer with touch-screen system.
2. One the programmable controller.
3. Six sets of ultrasonic system.
4. Traction inverter to control the main motor

5. Micro-motor four.
6. Two sets of step motors.

7. High quality ultrsonic sealing device from Germany to make sure the bag qulaity

Applications:

1-non woven hadle bag

2-non woven D-cut bag

3-non woven box bag with handle

4-non woven T-shirt bag

5-non woven shoes bag

6-non woven zipper bag

7-non woven laminating bag
